| CB-Funk Relais Teck 73266A - Coverage report |
|---|
| Description | CB-Funk Relais Teck 73266A |
| Frequency | 27 MHz |
| Base Name | CB-Funk Relais |
| Latitude | 48.57403745 ° |
| Longitude | 9.50939656 ° |
| Latitude | 48° 34' 26.53"N |
| Longitude | 009° 30' 33.83"E |
| QRA | JN48SN |
| UTM (WGS84) | 32U E537575 N5380231 |
| Elevation | 804.5 m |
| Base Antenna Height | 5 m |
| Base Antenna Gain | 3.0 dBi |
| Base Antenna Type | omni |
| Base Antenna Azimuth | 360 ° |
| Base Antenna Tilt | 40 ° |
| Mobile Antenna Height | 2.0 m |
| Mobile Antenna Gain | 2.15 dBi |
| Tx Power | 4.00000 W |
| Tx Line Loss | 3.0 dB |
| Rx Line Loss | 3.0 dB |
| Rx Threshold | 0.500 μV (-113.0 dBm) |
| Required Reliability | 70% |
| Strong signal margin | 10.0 dB |
| Weak signal field | -7.2 dBμV/m |
| Strong signal field | 2.8 dBμV/m |
| Weak signal covered area | 34411 km2 |
| Strong signal covered area | 17015 km2 |
| Weak signal population reached | 10616231 pop |
| Strong signal population reached | 5527913 pop |
| Landcover used | Yes |
| Two rays method used | Yes |
| User ID | CB-USER |
| Radio coverage ID | RM685093D06FDC_1 |
| Generated on | 12/29/2015 10:00:51 AM |
